Widely used in irrigation, spraying, carrying water from shallow water, civil building water supply and drainage system, water diversion in hill or mountainous areas.
Contact Us Product Center
Widely used in irrigation, spraying, carrying water from shallow water, civil building water supply and drainage system, water diversion in hill or mountainous areas.
(1)Motor and pump work together as a whole.
(2)Convenient structure, easy to be installed and dismantled.
(3)Covers a small area, convenient maintenance, steady and safe performance.
1. Power:50Hz, 380v(allowable deviation:-10%~+5%) three-phase AC
2. The pump should be all covered with water, diving depth should not less than 0.5m.
3. Water: should be clear water, sand content ≤0.02%, PH6.5-8.5,water temperature not more than 30°C
4. Actual use head:80%-105% of rated head
|
serial number |
specifications |
flux |
lift |
power |
remark |
|
|
|
|
|
|
outlet diameter |
|
1 |
QS10-34-2.2 |
10 |
34 |
2.2 |
1.5" |
|
2 |
QS10-54-3 |
10 |
54 |
3 |
1.5" |
|
3 |
QS10-72-4 |
10 |
72 |
4 |
1.5" |
|
4 |
QS10-90-5.5 |
10 |
90 |
5.5 |
1.5" |
|
5 |
QS10-102-5.5 |
10 |
102 |
5.5 |
1.5" |
|
6 |
QS10-105-7.5 |
10 |
105 |
7.5 |
1.5" |
|
7 |
QS10-120-7.5 |
10 |
120 |
7.5 |
1.5" |
|
8 |
QS10-144-7.5 |
10 |
144 |
7.5 |
1.5" |
|
9 |
QS15-26-2.2 |
15 |
26 |
2.2 |
1.5" |
|
10 |
QS15-52-4 |
15 |
52 |
4 |
1.5"
|
