Hot for home use and irrigation. Large volume discharge. Powered by air-cooled, 4-stroke gasoline engine .Large volume water discharge. Highly effective mechanical seal .Compact and light weight st
Contact Us Product Center
Hot for home use and irrigation
Large volume discharge
Powered by air-cooled, 4-stroke gasoline engine
Large volume water discharge
Highly effective mechanical seal
Compact and light weight structure
|
Model |
QGZ50-32-152F |
QGZ50-32-168F |
QGZ80-30-170F |
QGZ100-20-170F |
|
Inlet diameter |
2’,50 mm |
2’,50 mm |
3’,80 mm |
4’,100 mm |
|
Outlet diameter |
2’,50 mm |
2’,50 mm |
3’,80 mm |
4’,100 mm |
|
Max. lift,m |
25 |
28 |
26 |
20 |
|
Max. suction,m |
7 |
|||
|
Max. flow, m3/h |
26 |
35 |
60 |
78 |
|
Rated revolution,rpm |
3600 |
|||
|
Engine model |
152F |
168F |
170F |
177F |
|
Displacement,ml |
98 |
196 |
216 |
270 |
|
Engine type |
Single cylinder, OHC, four stroke, forced air cooling |
|||
|
Fuel tank capacity,L |
1.6 |
3.6 |
3.6 |
6.5 |
|
Oil capacity,L |
0.4 |
0.6 |
0.6 |
1.1 |
|
Starting system |
Recoil |
|||
|
Dimension,mm |
455*345*420 |
510*390*430 |
550*450*475 |
620*450*530 |
