Small Vibration Submersible Pumps

Model

Power

(W)

H max

(M)

Qmax

(L/MIN)

Outlet

(MM)

G.W

(KGS)

Packing Ssize

(MM)

Diameter

(MM)

VMP-50

180

50

16

12

3.0

300*115*145

80

VMP-60

280

60

18

14

3.5

300*110*180

100

VMP60-1

280

60

18

14

3.5

300*110*180

100

VMP-70

370

80

25

18

4.6

330*120*160

120

VMP70-1

370

80

25

18

4.6

330*120*160

120

VMP-80

430

65

35

22

5.8

300*150*165

150

Pump Characteristics:

Fluid temperature range

1-40 °C

Pump body

Aluminum

Max working pressure

8 bar

Motor body

Aluminum

Single phase

220V±5%/50HZ

Shaft

# 45 Steel

Suitable water

Clean water

Impeller

Rubber

Degree of protection

IP 68

Insulation class

B

Quality Control:

1)The high voltage 4000V test of each pump for safety control .

2)The noise control during test:During the pump working,the worker considers the

big noise pump(the sound caused by the rotor hit the motor)as the

non-conforming product. The big noise pump will cause the rotor fracture.

3)The pump must be tested the flow rate during the head is 40m.

The 40m head is the pump best usage performance for the user
