QYK series submersible slurry pumps are electro submersible centrifugal pumps designed for pumping abrasive and high density slurries in mining, heavy industry, civil construction and municipal applic
Contact Us Product Center
QYK series submersible slurry pumps are electro submersible centrifugal pumps designed for pumping abrasive and high density slurries in mining, heavy industry, civil construction and municipal applications.
1.Explosion proof for coal,mine,mining,pit, pitot ,ore washing,oil,mineral
2. Industries of petroleum, chemical, food, corrosive liquid, marine, sea water
3. Sewage treatment, agriculture, construction, water circulate, tunnel, bridge, river
1.Water temperature up to 40c
2.Max immersion depth 5.0m
3.Continuous Duty
4.PH value of medium 4-10
5.Minimum diameter of well/hole 55cm
6.5mm solid for 1.1kw or above,7mm for 2.2kw or above,10mm for 5.5kw above
| Item | Submersible slurry pump |
| Model | QYS |
| Material | 27% Chrome White Iron, SS 304,SS 316, or customized |
| Color | Decided by user |
| Mode | Submersible |
| Impeller | single impeller |
| Drive | Direct coupling |
| Seal | Packing seal or mechanical seal |
| Speed | 1460r/min,980r/min |
| Theory | Centrifugal pump |
| Structure | Single stage pump |
| Usage | High density slurries with solids etc. |
| Power | Electric motor |
| Standard | ISO |
| Application | Mining. civil construction, industry, dredging |
| Outlet diameter | 3.15-16inches |
| Capacity | 22-2400 m3/h |
| Head | 8.6-70m |
| Power | 7.5-315kw |
| Warranty | 1year |
| Certificate | ISO9001 |
| OEM | Acceptable |
| Max Solids Dia | 2.4 inches |
