Mainly used in high buildings life water supply, fire fighting system, automatic spraying water under the water curtain, long distance water transportation, water circulation in production process, su
Contact Us Product Center
1. Mainly used in high buildings life water supply, fire fighting system, automatic spraying water under the water curtain, long distance water transportation, water circulation in production process, supporting the use of all kinds of equipment and various production process water, etc.
2. It is used in city construction, factories, mines, the water is especially suitable for hotels, restaurants, entertainment refrigeration and air conditioning supply water.
Working Principle: Centrifugal, Multi-stage
Main applications: Water
Driver: Electric motor
Power Specs: 380/415 V 3phase; 50Hz/60Hz etc.
Max. Permissible fluid temperature: 80° C
Type of connection: Flange
Installation position: Horizontal
Casing/Inner parts material: Cast iron /Cast iron
Shaft seal type: Mechanical seal; Packing gland
Free passage: 0.1 mm
Maximum gravity: 1.03
Maximum drive rating: 180kW (242HP)
Maximum caliber: 6 inch (150mm)
Maximum dischrage head: 270m
Flow rate range: 18-155 m³ /h (30-2580L/m)
| Model | Capacity(m3/H) | Head (M) | Power(KW) | Rotary speed(rpm) | |
| 6-25x3 | 7.5 | 73.5 | 5.5 | 2950 | |
| 25-30x7 | 30 | 192.5 | 30 | 2950 | |
| 46-30x3 | 55 | 81 | 22 | 2950 | |
| 46-50x6 | 50 | 288 | 75 | 2950 | |
| 80-30x3 | 26 | 102 | 18.5 | 2950 | |
| 80-30x10 | 48 | 278 | 55 | 2950 | |
| 155-67x9 | 185 | 531 | 440 | 2950 | |
| 45-80x7 | 62 | 477 | 160 | 2950 | |
| 85-80x8 | 85 | 640 | 290 | 2950 |
