This pump is rugged.durable and builtto last.
This pump delivers a steady 95GPH(360LPH) at its maximum depth of 230 feet (70m) when supplied with 24VDC.
Its unique water-tight power connector stops water wicking and prevents potential condensation problems.
Great for livestock watering.irrigation,pondaeration,remote homes and cabins
1. For 4" wells or larger
2. Quick disconnect with "Watertight-Gland" Design Pat Pend
3. Corrosion-proof housing with stainless-steel fastener
4. Run dry without damage
5. State of the art solid diaphragm
6. Stainless Steel Fastener
7. Pump Design: Positive Displacement 3 Chamber Diaphragm Pump
8. Motor: Permanent Magnet Thermally Protected
9. Wire Length:3M
| Pump Design | Positive Displacement 3 Chamber Diaphragm Pump |
| Motor | Permanent Magnet, Thermally Protected |
| Voltage | 24VDC Nominal |
| Amps | 4.0A Maximum |
| Internal Bypass | 105-110PSI Max.(7.2-7.5 Bars) |
| Maximum Lift | 230 feet Maximum (70 Meters) |
| Maximum Submersion | 100 Feet Maximum (30 meters) |
| Outlet Port | 1/2'' (12.7mm) Barbed Fitting |
| Inlet: | 50Mesh Stainless Seel Screen |
| Materials | High Strength Engineered Plastics,Stainless Steel Fasteners |
| Typical Applications | Potable Water Well Pump |
| Model |
Volt (V) |
Flow rate (LPM) |
Max.Lift (M) |
Max.Submersible (M) |
Amps (A) |
Packing Size (mm) |
N.W/G.W ( kgs) |
| YM1240-30 | 12 | 6.0 | 70 | 30 | 4.0 | 355*130*110 | 2.9/3.0 |
| YM2440-30 | 24 | 6.0 | 70 | 30 | 8.0 | 355*130*110 | 2.9/3.0 |
