Shandong Weixin Agricultural
Science and Technology Co., Ltd.
+86-17753785400 contact@chinacoalintl.com
For household water supply, well water drawing, pressurization of tap water and water heater pipeline, gardening spraying and vegetable greenhouse watering.
Contact Us Product Center
1. Max. fluid temperature: +80℃
2. Max. solid impurity: 0.1%
3. Max. particle size: 0.2mm
4. Fluid PH value: 6.5-8.5
5. Supply frequency: 50 hz
6. Voltage: single phase 220v, three phase 380v
7. Voltage range: 0.9-1.1 times of rated voltage.
For household water supply, well water drawing, pressurization of tap water and water heater pipeline, gardening spraying and vegetable greenhouse watering.
| MODEL | OUTPUT POWER | MAX.FLOW | MAX. HEAD | MAX.SUCT | START PRESSURE | INLET/OUTLET | GW | PACKING SIZE | |
| kw | hp | l/min | m | m | bar | mm | kg | mm | |
| BQ-150 | 0.15 | 0.2 | 17 | 15 | 8 | 0.5 | 20(3/4") | 5.5 | 275x200x235 |
| BQ-230 | 0.23 | 0.3 | 25 | 25 | 8 | 1 | 25(1") | 7.2 | 280x220x255 |
| BQ-280 | 0.28 | 0.37 | 30 | 25 | 8 | 1 | 25(1") | 7.7 | 280x220x255 |
| BQ-350 | 0.35 | 0.4 | 25 | 30 | 8 | 1.2 | 25(1") | 11 | 310x250x310 |
| BQ-430 | 0.43 | 0.6 | 30 | 35 | 8 | 1.2 | 25(1") | 11 | 310x250x310 |
| BQ-530 | 0.53 | 0.75 | 35 | 35 | 8 | 1.5 | 25(1") | 13.2 | 330x260x310 |
| BQ-630 | 0.65 | 0.9 | 40 | 40 | 8 | 1.5 | 25(1") | 13.2 | 330x260x310 |
| BQ-760 | 0.8 | 1.1 | 45 | 45 | 8 | 1.8 | 25(1") | 16.8 | 350x260x330 |
| BQ-860 | 0.9 | 1.2 | 50 | 50 | 8 | 2 | 25(1") | 16.8 | 350x260x330 |
| BQ-1200 | 1.2 | 1.6 | 55 | 60 | 8 | 2.5 | 32(1¼”) | 23.4 | 370x270x350 |
| BQ-1500 | 1.5 | 2 | 60 | 65 | 8 | 3.5 | 40(1½") | 29.8 | 570x310x670 |
| BQ-1800 | 1.8 | 2.4 | 70 | 70 | 8 | 3.5 | 40(1½") | 30.3 | 570x310x670 |
