1. Mainly composed of frame, reel, water turbine, HDPE hose, gearbox and water carriage, tire and accessories. 2. Easy operation and installation with simple and compact structure, ok to operate by 1-
Contact Us Product Center
1. Mainly composed of frame, reel, water turbine, HDPE hose, gearbox and water carriage, tire and accessories.
2. Easy operation and installation with simple and compact structure, ok to operate by 1-2 persons.
3. PE Hose can be automaticly rewinded to save labor costs.
4. 360°sprinkling coverage to ensure the farm irrigation efficienct and uniform
5. Widely used for fruit and vegetable irrigation, farmland irrigation, power plantetc.
7. Water spray car can retrieve the tube fast even under the low flow conditions, up to 180m/h, help to adjust the sprinkler area according to the actual irrigation requirements.
| XF Series | Model | PE-Hose Dia. | PE-Hose Length | Max. Flexible Length | Flow Rates (m3/h) |
Nozzle Dia. (mm) |
Working Pressure(Bar) |
| HR50 | 50-150Tx | 50 | 150m | 2×180m | 7--16 | 11--14 | 3.5 - 7.6 |
| HR65 | 65-220Tx | 65 | 220m | 2×260m | 13 - 32 | 14 - 22 | 3.5 - 10.0 |
| 65-250Tx | 65 | 250m | 2×290m | 13 - 32 | 14 - 22 | 3.5 - 10.0 | |
| 65-340TX | 65 | 340m | 2×380m | 13 - 28 | 14 - 22 | 3.5 - 10.0 | |
| HR75 | 75-300TX | 75 | 300m | 2×345m | 13 - 38 | 14 - 26 | 3.5 - 10.0 |
| 75-350TX | 75 | 350m | 2×390m | 13 - 38 | 14 - 22 | 3.5 - 10.0 | |
| 75-400TX | 75 | 400m | 2×435m | 13 - 30 | 14 - 20 | 3.5 - 10.0 | |
| HR90 | 90-250TX | 90 | 250m | 2×300m | 17 - 65 | 16 - 30 | 3.5 - 10.0 |
| 90-300TX | 90 | 300m | 2×350m | 17 - 65 | 16 - 30 |
3.5 - 10.0
|
