1. High Performance 3 Row Corn Harvester is a Self-propelled harvesting machine, hydraulic step-less speed adjustment 2. Cutter bar hydraulic control lifting, good suitability of height and row spaci
Contact Us Product Center
1) wheel type self-propelled High Performance 3 Row Corn Harvester
2)2.5CBM grain tank
3)suitable cabin
1. High Performance 3 Row Corn Harvester is a Self-propelled harvesting machine, hydraulic step-less speed adjustment
2. Cutter bar hydraulic control lifting, good suitability of height and row spacing
3. Huge grain tank, hydraulic control turning, high efficiency and save time
4. Compact structure, advantages of agility, lower loss and impurities
5. Stalk cutting back to the field meets customer’s requirements
6. Equipped with reversing radar, improve the driving safety
|
Type |
High Performance 3 Row Corn Harvester |
|
Working rows |
3 |
|
Total loss rate |
≤4 |
|
Broken rate |
≤1% |
|
Roughage content |
≤1.5% |
|
Reliability |
≥95% |
|
Engine |
75kw |
|
Dimension (L×W×H) |
6400×2150×3450mm |
|
Weight |
4850 kg |
|
Oil consumption |
≤30Kg/ hm2 |
|
Ground clearance |
350mm |
|
Maximum unloading height |
1650mm |
|
Back-to-field machine type |
Flail knife(44 pieces) |
|
Width of back-to-field machine |
1800mm |
|
Grain tank |
2.5 m3 |
