Model 4LZ-1.2 Mini Combine Harvester for Harvesting Rice Wheat is small Combine Harvester, is suitable for rice, wheat, rape seeds and other granular crops, the light weight with wider rubber track, i
Contact Us Product Center
Model 4LZ-1.2 Mini Combine Harvester for Harvesting Rice Wheat is small Combine Harvester, is suitable for rice, wheat, rape seeds and other granular crops, the light weight with wider rubber track, it performance very good in water field.
This 4LZ-1.2 Mini Combine Harvester for Harvesting Rice Wheat is easy for operation and maintenance, it is a safety and energy-saving machine.
| Overall Dimension | Length×Width×Heights ( mm ): 4200×1650×2010 |
| Weight (kg) | 1700 |
| Feeding Capacity( kg/s ) | 1.2 |
| Harvesting Capacity(hm²/h): | 0.1-0.3 |
| Engine | Engine Model: QC2105; QC2110 |
|
|
Rated Power ( kw/hp ): 28.6/38.9; 32/43 |
|
|
Engine Type: Water-Cooled, 2-Cylinder, DI-Injection, Vertical Diesel. |
| Driving System | Crawlers(mm): 350*90*42, 400*90*42 |
|
|
Minimum Ground Clearance (mm): 280 |
|
|
Type of Gearbox: Mechanism + HST(3F, 3R) |
| Cutting header | Pickup Reel: Type:Tooth ( off-centre ); Diameter( mm ): 900; Nos: 5 |
|
|
Cutting Bar Length ( mm ): 1400 |
|
|
Rape Seed Extension: Optional |
| Threshing & Separating | Threshing System: Spiked Tooth Axial Flow |
| & Cleaning System | Threshing Cylinder Size Diameter × Length ( mm ): 550×1070 |
|
|
Refresher: Blade-Rotation |
|
|
Vibrating Sieve: Adjustable Seive / Meshing Seive ( optional ) |
|
|
Blower Fan: Type: Swirl; Diameter( mm ): 260; Nos: 2 |
| Grain Storing | Mechanism Option: Grain Tank with Unloading Auger, Capacity: 432L |
|
|
Manual Operation. |
