1.3 Working Rows Corn Harvester Machine uses distribution augers improves grain tank capacity 2.Good command of snapping roll to prevent from jam and gain high rotate speed.
Contact Us Product Center
1.3 Working Rows Corn Harvester Machine uses distribution augers improves grain tank capacity
2.Good command of snapping roll to prevent from jam and gain high rotate speed.
3.Adaptation spaced 450-900 MM
4.High efficiency with 0.27-0.53 hectare per hour and higher than similar products by 0.07-0.13 hectare per hour.
5.Header ascend and descend uprightly with no alter of harvesting angle.
6.Tractor as center to do free motion.
4.Hydraulic control of ascend and descend to ensure convenient and agile operation
|
Model |
wx-2 |
wx-3 |
wx-4 |
|
Number of Rows |
2 |
3 |
4 |
|
Distance between Rows mm) |
450 -900 |
550 - 850 |
550 - 850 |
|
Heightmm) |
> 600 |
> 600 |
> 600 |
|
Widthmm) |
1400/ 1650 |
1650/ 1800 |
1650/ 1800 |
|
Productivityhec/h) |
0.27-0.40 |
0.27-0.53 |
0.53-0.80 |
|
Matched powerhp) |
50-70hp |
70-90hp |
70-90hp |
|
Stalk Cut Qualified Ratio |
≥90% |
≥90% |
≥90% |
|
Grain Broke Ratio |
≤2% |
≤2% |
≤2% |
|
Reliability |
95% |
95% |
95% |
