Wheat Harvester With Double Threshing Rollers working width 1600/1800/2000mm hydraulic steering and lifting double threshing rollers
Contact Us Product Center
Wheat Harvester With Double Threshing Rollers working width 1600/1800/2000mm
hydraulic steering and lifting
double threshing rollers
1. Wheat Harvester With Double Threshing Rollers is specialized for harvesting wheat
2. Adopt Hydraulic steering and running control, and the Hydraulic control the header lifting
3. 1800mm cutter width is suitable for blockette field
4. Double re-threshing rollers, the grain is very clean
5. Strong reels and spring-tooth
|
Model |
4LZ-2.0 |
|
|
Type |
4x2 wheel driven, self propelled |
|
|
Cutting Width |
1600/1800/2000mm |
|
|
Diesel Engine |
Model |
4102 |
|
Power |
65hp/48kw |
|
|
Rotary Speed |
2600 r/min |
|
|
Unloading |
mechanical unloading |
|
|
Tank capacity |
1m3 |
|
|
Gearbox |
3x2+1 |
|
|
Ground Clearance |
310mm |
|
|
Wheel base |
1985mm |
|
|
Wheel tread |
Front |
1300-1200mm, two-stage adjustable |
|
Rear |
1290-1210mm, two-stage adjustable |
|
|
Tire size |
Front |
9.5-20 |
|
Rear |
6.0-16 |
|
|
Tire pressure |
Front |
0.28 MPa |
|
Rear |
0.36 MPa |
|
|
Oil Consumption |
≤27 Kg/hm² |
|
|
Oil Tank Capacity |
65L |
|
|
Working Productivity |
4-6 Mu/H (0.27-0.4Hec/H) |
|
|
Feeding speed |
1.5 Kg/s |
|
|
Working speed |
2.48-16 Km/h |
|
|
Total Weight |
2800kg |
|
|
Overall Dimension |
5800mm |
|
|
2400mm |
||
|
3000mm |
||
