1) Tractor Combine Harvester Machine For Maize Corn Forage supporting reel protect cover makes repair and maintenance convenient. 2) Hidden front ladder makes operation simple and getting on/off conve
Contact Us Product Center
1) Tractor Combine Harvester Machine For Maize Corn Forage supporting reel protect cover makes repair and maintenance convenient.
2) Hidden front ladder makes operation simple and getting on/off convenient.
3) Vibrating sieve and twice re-threshing and seperating makes corn cleaner
4) Clutch on straw disintegrator can protect the harvester from being damaged with sudden power failure.
5) Hydraulic control of real lifting and corn turning over
6) Infrared monitor system
7) Straw crusher set: can meet different needs according to users and be operated conveniently.
| 1. Commodity Name | 2.Model | 3.Description | |
| Silage Harvester (HS code:8433510090) | 4QZ-2200 |
1. It’s mainly composed of header, feeding device, throwing device, engine, underpan, driving room, hydraulic system, electric system, etc. 2. It can complete harvesting, cutting,smashing, throwing and loading continuously during one operation. |
|
| 4. product's Technical Parameters: | |||
| Item | Unit | Techinical Specifications | |
| Overall dimension(L*W*H) | mm | 7800*2500*4500 | |
| Working width | mm | 2200 | |
| Working speed | Km/h | ≤6 | |
| Whole weight | kg | 7400 | |
| Stubble height | mm | ≤150 | |
| Cut lenght of straw | mm | 7~35 | |
| Diameter of cut roller | mm | ||
| Rotation speed of cut roller | R/min | 960 | |
| Knife type of cut roller | disc saw blades | ||
| Throw distance(max) | m | 10 | |
| Height of throw | m | 4.5 | |
| Minimum turning radius | mm | ||
| Left turning | 7750 | ||
| Right turning | 7500 | ||
| Engine | YC6B160Z-T10 | ||
| Engine power | Kw/hp | 118kw | |
| Engine output rotation speed | r/min | 2200 | |
| Wheel base(front) | mm | 1970 | |
| Wheel base(rear) | mm | 1846-2145 | |
| Axle base | mm | 3000 | |
| 5. Price Terms: USD43,500 /Set FOB Qingdao,China | |||
| 6. Payment Terms:30% prepayment by T/T, the balance is paid off by T/T against the copy of B/L | |||
| 7. Loading port: Qingdao port | |||
| 8. Packing: Nude packing Roll-roll shipment | |||
| 9.Shipment Time: within 20 days against the deposit is received | |||
| 10.Warranty period:12 months | |||
