1. Agriculture Machine Mini Grain Combine Harvester equipped with optimized Threshing Mechanism: Bigger double rollers, better threshing results and separation, additional re-threshing devices.
2. Advanced Cleaning Mechanism: Fan and double fish shakers, more dependent, high cleanliness and lower loss.
3. Cutter Swing Ring Transmission: Compact structure, move smoothly and little vibration.
|
Type |
|
Wheel full feed self-propelled |
|
|
Cutting Width |
mm |
1800mm |
|
|
Feed |
Kg/s |
2.0 |
|
|
Running speed |
Km/h |
2.48-16 |
|
|
Diesel Engine |
Model |
|
4102 |
|
|
Power |
KW |
48 |
|
|
Rotate Speed |
r/min |
2600 |
|
Average Oil Consumption per Hectare |
Kg/hm² |
≤27 |
|
|
Working Productivity |
Mu/H |
4-6 (0.27-0.4Hec/H) |
|
|
Total Weight |
kg |
2800 |
|
|
Dimension (L×W×H) |
mm |
5800 |
|
|
|
|
2400 |
|
|
|
|
3000 |
|
|
Ground Clearance |
mm |
310 |
|
|
Header |
Reel Type |
|
Spring-tined |
|
|
Reel Diameter |
Mm |
Φ900 |
|
|
Reel Bat |
Piece |
5 |
|
|
Cross auger Type |
|
Screw auger, eccentric extensible link |
|
|
Cross Auger Diameter |
mm |
Φ500 |
|
|
Clearance between Auger and Bed Plate |
mm |
12-20 |
