Waste Water Treatment Mechanical Grille Bar Screen Machine

Introduction of Waste Water Treatment Mechanical Grille Bar Screen Machine

Waste Water Treatment Mechanical Grille Bar Screen Machine is composed of main frame, driving device, tooth harrow and transmission chains. Teeth with ABS, nylon 6, nylon 1010 or stainless steel material are ranked on axis to form a seal chain. It pushes waste to flow into tank instead of to the top guided by rail and wheel. And brush will clean the residue on teeth. It is installed at water inlet of secondary grill and other water intake units where no large particles are in water.It is also can be used for industrial and municipal sewage of industries such as paper mill,textile, leather,wine and suggar making,fishing etc. It is suitable for usage at premier and secondary fence of water inlet of water intake units.

Parameters of Waste Water Treatment Mechanical Grille Bar Screen Machine

Model	Grille width	chanel width	grille interstice(mm)	grille speed(m/min)	discharge height	grille angle	power(kw)
GSC300	300	500	3-60	2.2	by user	60-80°	0.75
GSC500	500	700	3-60	2.2	by user	60-80°	0.75
GSC800	800	900	3-60	2.2	by user	60-80°	1.1
GSC1000	1000	1200	3-60	2.2	by user	60-80°	1.1
GSC1200	1200	1400	3-60	2.2	by user	60-80°	1.5
GSC1500	1500	1700	3-60	2.2	by user	60-80°	1.5
GSC1800	1800	2210	3-60	2.2	by user	60-80°	2.2
GSC2200	2200	2610	3-60	2.2	by user	60-80°	3

Pictures of Waste Water Treatment Mechanical Grille Bar Screen Machine

•
