Small Agricultural Peanut Harvest Machine is a gear drive min harvest machine, suitable for home, small farm use. it can apply to peanut, potato, and other root vegetable.
Contact Us Product Center
Small Agricultural Peanut Harvest Machine is a gear drive min harvest machine, suitable for home, small farm use. it can apply to peanut, potato, and other root vegetable.
Working depth of Small Agricultural Peanut Harvest Machine can be adjustable, the broken rate is very low, easy operate. Small Agricultural Peanut Harvest Machine is a good helper for farmer.
| Model | 4U—600A | 4U--600 | 4U—600B | 4UZ-600(4UZ -1) | 4U—1300 | 4U—1300B | 4U--1650 |
| Working row | 1 | 1 | 1 | 1 | 2 | 2 | 2 |
| Working mode | casting | casting | Stacking and automatic discharging | Vibration spread | Casting | Self-loading | Self-loading |
| working width | 60cm | 60cm | 60cm | 60cm | 130cm | 130cm | 165cm |
| Working Efficiency | 3--5(mu/hr) | 5--8(mu/hr) | 8--15(mu/hr) | ||||
| Net weight | 100kgs | 180kgs | 200kgs | 160kgs | 700kgs | 800kgs | 1200kgs |
| Matched tractor | walking tractor | 4 wheeled tractor | |||||
| Matching power | 8—15HP | 22--35HP | 22--35HP | 22--35HP | 35--80HP | 50--80HP | 70--120HP |
| Working depth | 20cm | 25cm | 25cm | 25cm | 25cm | 25cm | 25cm |
| Exposing rate | ≥96% | ||||||
| Breakage rate | ≤2% | ||||||
| PTO speed | 1000rpm | 560/1250rpm | 560/1250rpm | 560/1250rpm | 560rpm | 560rpm | 560rpm |
| Overall dimension(mm) | 900*700*700 | 1800*1000*980 | 2400*900*900 | 1200*1000*750 | 2300*1800*1000 | 2800*3200*3100 | 3300*3900*3100 |
| Packing size(mm) | 1150*1000*800/2 | 1650*850*750/2 | 1650*850*750/2 | 1100*1200*980/2 | 2100*1600*700/2 | 2600*2100*1000/1 | |
