Tractor Pto Trencher

Tractor Pto Trencher

Date:2015-06-13     Label:

Tractor Pto

Trencher

Ditch machine is a kind of high efficient and practical new chain ditch device. It is mainly composed of power system, reduction system, chain drive system and points soil system composition. After th

Contact Us Product Center

Introduction of chain ditcher

Ditch machine is a kind of high efficient and practical new chain ditch device. It is mainly composed of power system, reduction system, chain drive system and points soil system composition. After the diesel through the belt in the rotation transmitted to the clutch, the driver walking gearbox, drive shaft, the rear axle to achieve the forward or rearward linear movement of the chain type trencher.

Application of chain ditcher

The wide range of application, simple structure, low cost, use dismantling is convenient, ditch of good quality, high efficiency and has the ditch, broken cutting, even row soil a complete characteristics. Suitable for dryland cotton, wheat, rape and other field drain ditches. Its application brings a lot of convenience to the people's production and life and improve the work efficiency and the realization of some agricultural modernization. And some ditcher device results simple economic use, console belt, and not easy to wear. In the development of science and technology, the society is progressing. Split groove machine application people will also have the greater increase. Let people reduce a lot of headache to duplicate work things.

Main components of chain ditcher

1. Tractor 2. Suspension frame 3. Oil cylinder 4. Transmission 5. Row soil stir dragon 6. Article ingot 7. Chain knife 8. Chain tension mechanism 9. Drag soil leveling mechanism.

Features of chain type ditcher

1) Significant economic benefits: Low investment and quick, efficiency of a machine can replace up to dozens of people.
2) Simple structure, convenient operation, easy maintenance.
3) High efficiency, Ditching depth, width can be adjusted.
4) And supporting the use of tractors, can adapt different jobs, when not be removed without affecting the tractor other uses.
5) Good quality, long life: Cutting blades and chains are made of special materials and technology, long service life.

Parameters of chain ditcher

Models unit ZYHL-40 ZYHL-50 ZYHL-70
Working width (adjustable) cm 10-30 10-50 30-50
Working depth (adjustable) cm 50-120 50-150 50-230
Matched power hp 15-55 55-75 75-100
Working efficiency m/hr 150-400 150-500 150-700
Net Weight kg 120 340 400


Tractor Pto Trencher


Tractor Pto Trencher


开沟机

PHOTOS OF

Tractor Pto Trencher
