1.Material: PVC Pipe 2.Diameter: 20 - 160mm 3.Thickness: 2.0 - 26.0mm 4.MPa: PN1.25 - PN2.5 5.Colors: white, gray, green,blue,and other colors available upon requests.
Contact Us Product Center
1.Material: PVC Pipe
2.Diameter: 20 - 160mm
3.Thickness: 2.0 - 26.0mm
4.MPa: PN1.25 - PN2.5
5.Colors: white, gray, green,blue,and other colors available upon requests.
6.Resistant to high temperatures (95°c), good impact strength (over 2.5 MPa)
| PIPE SERIES OUTER | S5 / PN1.25(cold water) | S4 / PN1.6(cold water) | S3.2 / PN2.0(hot water) | S2.5 / PN2.5 (hot water) |
| Specification(mm) | wall thickness | wall thickness | wall thickness | wall thickness |
| 20 | 2.0 | 2.3 | 2.8 | 3.4 |
| 25 | 2.3 | 2.8 | 3.5 | 4.2 |
| 32 | 2.9 | 3.6 | 4.4 | 5.4 |
| 40 | 3.7 | 4.5 | 5.5 | 6.7 |
| 50 | 4.6 | 5.6 | 6.9 | 8.4 |
| 63 | 5.8 | 7.1 | 8.7 | 10.5 |
| 75 | 6.8 | 8.4 | 10.3 | 12.5 |
| 90 | 8.2 | 10.1 | 12.3 | 15 |
| 110 | 10.0 | 12.3 | 15.1 | 18.3 |
