Quartz sand filter is one of the main equipment of the deep treatment of the water, and the selection of filter material generally is quartz sand or activated carbon. It is widely used for water pretr
Contact Us Product Center
Quartz sand filter is one of the main equipment of the deep treatment of the water, and the selection of filter material generally is quartz sand or activated carbon. It is widely used for water pretreatment, such as, pure water, drink water in food, mineral water and water in electronics,printing and dyeing, paper making, chemical industries, and it is also used to filtrate industrial wastewater after secondary treatment. And it is used for deep filtration of water reuse system and water treatment system of swimming pool. There is very good removal effect on suspended solids in industrial wastewater.
The device has simple structure and it is convenient to operate and maintain; The operation can realize the automatic control, high filtration efficiency, small resistance, large processing flows, less fequency of recoil. There is two washing systems: gas washing and water washing and it has the function of putting an end to short flow.
Filter filtration rate: 8 ~ 300m / h
Backwash time: 8 to 10
Working pressure: ≤ 0.6Mpa
Flushing filter head loss: 0.8&
Water outlet: 2-5mg/L
Water inlet: <10mg/L
Water outlet: <2mg/L
Design temperature: 5 ~ 4000C
Single sand filter Height: 700mm (height for circulating water sand filter 500mm)
Backwash strength: 13 ~ 15L / s m2?
Double filter Height: sand filtration height 500mm, 500mm height anthracite
Backwash swelling degree: 40 ~ 50%
Activated carbon / cationic resin filter Height: 2000mm
