5 kg Agriculture Spraying Drone designed with broken paddle protection function, when the aircraft lost a power to support the accident, the aircraft is still controllable, greatly reducing the risk o
Contact Us Product Center
1,5 kg Agriculture Spraying Drone designed with broken paddle protection function, when the aircraft lost a power to support the accident, the aircraft is still controllable, greatly reducing the risk of falling machine
2,The hardware architecture can effectively reduce the interference of the magnetic field and the special environment on the aircraft GPS.
3, Plan the air line through the ground station, can be realized by self spraying, without manual operation (can be customized)
4,Eight axes sixteen propeller ,with no Coaxial design . smoother flight, smoother operation, fast response speed
5,Equipped with FPV system and video overlay system, the aircraft can be effectively monitored in real time, and the security is higher.
6, Internal circuit of a vehicle by the hub board changed to integrated circuit board, the effective realization of the modular design for easy assembly and disassembly, improve efficiency (patented)
7, When flying and working continuous,the motor temperature of 5 kg Agriculture Spraying Drone not above 60 degree, improve a lot for the motor service life.
|
Specification |
Model:FH-8Z-5 |
|
Size(L*W*H) |
1150*1150*500mm |
|
Aircraft folding size |
435*435*500mm |
|
Aircraft weight |
7kg |
|
Maximum takeoff weight |
14kg |
|
Aircraft pesticide load |
5kg |
|
Propeller |
15 inch carbon fiber plant protection special propeller |
|
Spraying task system |
1 sets of kit, dispersion spray system, booster pump |
|
Remote control |
2.4G Nine channel |
|
Power battery |
High performance lithium polymer lithium battery (22.2V/16000mA) |
|
charger |
High power lithium battery balance charging equipment (can charge 2 pcs at the same time, half an hour full) |
|
UAV self stabilization system |
yes |
|
Spraying system |
Diffuse atomization nozzle (a group of *6) |
|
Motor speed |
1200rpm/min |
|
Aircraft endurance time |
10～15min |
|
Spraying height |
Field operation 0-200 M |
|
Spraying area |
4 meters |
|
Control efficiency |
1～3 acre/min |
|
Spray flow |
0.25-0.75L/min(multi nozzle) adjustable |
|
Flying speed |
0 -8meter/second(can be adjusted according to needed speed) |
|
Flying height |
0～200meter |
|
Hover |
Arbitrary position direction air hover |
|
Flight attitude |
Flying in any direction, can be reversed to fly, emergency brake |
|
Takeoff / landing time |
≤1minute |
|
Body material |
Carbon fiber |
|
Temperature range |
-15℃～40℃ |
|
Battery power performance |
charge-discharge 300-500 times |
|
Rack life |
≥5 years |
|
Maximum efficiency |
200-300acre/day |
