20inch lawn mower Engine Type: 1P65F 4 Stroke air cool Cutting width 500mm Maximum power:3.4kw/3600rpm Displacement:140cc
Contact Us Product Center
20inch lawn mower
Engine Type: 1P65F 4 Stroke air cool
Cutting width 500mm
Maximum power:3.4kw/3600rpm
Displacement:140cc
| Gasoline engine | 1P65F, single-cylinder, four-stroke, forced air cooling |
| Displacement | 139ml |
| Horsepower | 5HP/6HP |
| Bore * Stroke | 64 * 42mm |
| Maximum power and corresponding speed | 3.4kw/3600 (r / min) |
| Maximum torque and corresponding speed | 7N • m / 2600 (r / min) |
| Fuel consumption | ≤ 395g / (kW • h) |
| Lubricating oil consumption | 5.0g (kW • h) |
| Ignition | Transistor ignition magnet |
| Direction of rotation | Counterclockwise |
| Low-load speed | ≤ 1700r/min |
| Fuel Type | 90 # |
| Starting method | Recoil start |
| Walk way | push by hand |
| Wheel size | front: 7 inches, rear: 10 inches |
| Spark plug gap | 0.70-0 .80 mm |
| Fuel tank capacity | 1.5L |
| Collecting bag Volume | 60L |
| Mowing width | 460mm |
| Mowing height | 20-80mm (7-speed adjustable) |
| Chassis | 20 "steel chassis, with lateral line |
| Packing size | 760 * 570 * 440mm |
| N.W./G.W. | 38/40 kg |
| Application | Suitable for families, factories, schools, hospitals, villas, property companies. |
