1.The Features of the Grain Dryer machine:mobile grain dryer
A. simple structure, easy to use.
B.high production efficiency, fast drying speed, the grain circulation speed, high blast temperature can be used, but not make the grain temperature too high, the food was in a state of continuous mixing and flow all the time, so the uniform drying, moisture evaporates faster.
C.the tempering drying simultaneously, after high temperature drying of grain in vertical spiral send first vertebral body upper part, for a short period of time the tempering, easy to spread within the grain moisture, conforms to the law of grain drying, is helpful to ensure food quality.
D.the machine use shorter drying period and recovery period of circulation flow, instead of a tower slow flow, the fuselage height decreases greatly.
E.high speed discharge, easy to feed.Although the dryer intermittent operation, the average efficiency is high, unloading grain only about 15 minutes, drying is not affected by raw grain moisture, moisture is high cycle time, time, moisture low cycle less time.Do not need to cost due to install dryer construction costs.
Tower dryer is also called the grain dryers, grain drying machine is an ideal equipment for drying grain and oil, processed products from the top input, through the feeding device, to ensure that the equipment always in full load condition during operation. After turning inward bottomless v-shaped flap and processing with staggered joint action of multiple rows of "V" baffle, makes possible the mix of processed products, but also as dry air in and out of the channel, the fan will be used gas into the collector, purification, most of the dry air can be recycled, so save the fuel consumption.
|
The temperature that the grain allowed |
||||||
|
grain |
Grain layer thickness (cm) |
grain temperature permissible heated |
||||
|
|
|
Grain as feed (ºC) |
Grain as seeds (ºC) |
Commodity grain(ºC) |
|
|
|
corn |
50.8 |
80 |
40 |
60 |
|
|
|
wheat |
50.8 |
80 |
40 |
60 |
|
|
|
barley |
50.8 |
80 |
40 |
40 |
|
|
|
oats |
91.4 |
80 |
40 |
60 |
|
|
|
rice |
45.7 |
|
40 |
40 |
|
|
|
beans |
50.8 |
|
30 |
40 |
|
|
|
sorghum |
50.8 |
80 |
40 |
60 |
|
|
|
rapeseed |
50.8 |
|
40 |
70 |
||
|
Total weight(t) |
7.5 |
|
Area size(m) |
L*W*H:5*3*10 |
|
Capacity(t/h) |
5 |
|
Consumption of calorie (kcal/h) |
300000 |
|
Fuel consumption |
Gas 35m³/h |
|
Biomass fuel 70kg/h |
|
|
Straw 150kg/h |
|
|
Coal 50kg/h |
|
|
Diesel 30kg/h |
|
|
Total power(kw) |
19.4 |
|
actual power consumption(kw) |
16 |
|
Container |
One 40HQ |
