Mini Loader With CE Certificate. Engine: Japanese Kubota, Perkins engine are optional. Engine Power: 26HP with 3 cylinder diesel engine Rated Operating Capacity: 333Kg Operating Weight(out bucket): 10
Contact Us Product Center
Mini Loader With CE Certificate.
Engine: Japanese Kubota, Perkins engine are optional.
Engine Power: 26HP with 3 cylinder diesel engine
Rated Operating Capacity: 333Kg
Operating Weight(out bucket): 1069Kg
Big capacity plastic fuel tank
Heavy-duty 2-stage air cleaner
Light footprint: 5.1psi(35KPa) ground pressure
45 lpm auxillary hydraulic flow
|
Model |
ZY522 |
||
|
Moving type |
crawel type |
||
|
Max. Length (without bucket) |
1954 mm |
||
|
Max. width |
1040 mm |
||
|
Max. height |
1524 mm |
||
|
Speed |
0-15km/h |
||
|
Rated operating capacity |
330kg |
||
|
Tipping capacity |
953kg |
||
|
Operating weight (with bucket) |
1069KG |
||
|
Engine |
Type model |
Perkins engine | |
|
Fuel/cooling |
Diesel/Liquid |
||
|
Rated speed |
3000 r/min |
||
|
Power |
26hp |
||
|
Oil tank capacity |
34.07L*2 |
||
|
Hydraulic system |
Hydraulic oil flow |
45 L/min | |
|
Traveling pressure |
210bar |
||
|
Working pressure |
175bar |
||
|
Byfraulic tank capcity |
53L |
||
|
fittings |
Quick coupler |
||
|
Electrical system |
Battery capacity |
55Ah |
|
|
System valtage |
12v |
||
|
Optional attchments |
4 in 1 bucket |
||
|
Auger drive |
|||
|
Two set quick connector |
|||
