1.The corn separator machine is used for peeling the corn from the corn body without breaking the corn cob. 2.The corn separator machine is consists of a rack, chassis, roll axis and a network of prot
Contact Us Product Center
1.The corn separator machine is used for peeling the corn from the corn body without breaking the corn cob.
2.The corn separator machine is consists of a rack, chassis, roll axis and a network of protection.
3. The corn separator machine is the equipment that put the corn outer skin peeling off after the corn harvest.It replaces the manual stripping tension and heavy labor, reducing the labor intensity ,
4.Type A is multi-usage can peel, it can threshing.B type high efficiency and can be connected to all kinds of power machinery, including tractors, gasoline engine, diesel engine and motor, and the micro tillage machine.
This machine consists of a single-phase four motor power input spindle assembly through a gear transmission, driving the tore skin Room, the relative rotation of two pairs of steel to tear the skin chamber tear roller adjust the rocker arm bearing adjustment screw by a spring pressure, the two pairs of tear roller close contact, cluster into the tearing room, steel and tear on the roller tearing claw nail shell bract, the relative rotation of two pairs of roller bract rolling the housing, cover and the cover above to get the rubber adjustment board in the rotation to suppress ear, rely on two rollers rotating force and the pressure of the spring opened bract, so with the cluster separation, to tear the skin.
|
Model |
Capacity |
Motor(KW) |
Weight(Kg) |
Out size(mm) |
|
FX-600A1 |
2000-3000kg/h |
2.2 |
60 |
1100*450*850 |
|
FX-600A2 |
3000-4000kg/h |
3 |
70 |
1050*500*900 |
|
FX-600B1 |
2000-3000kg/h |
4kw |
65 |
1050*450*850 |
|
FX-600B2 |
3000-4000kg/h |
4kw |
75 |
1050*500*900 |
