It is domestic initiative, perfect combination of hammer mill and wood crusher, with functions of both machines, which makes the functions of the machine more powerful and application wider.
Contact Us Product Center
1).It is domestic initiative, perfect combination of hammer mill and wood crusher, with functions of both machines, which makes the functions of the machine more powerful and application wider.
2).Main purposes: Crushing and grinding of wood, tree trunks, branches, straw, bamboo stumps, smashing of materials such as pieces of wood, small twigs, leaves, bark, bamboo poles, bamboo leaves, feed, chemical raw materials, etc.
3).It can be installed in the aircraft trolleys, or agricultural vehicles, with the driving force of the motor, diesel or gasoline engine, can also be mobile or sentinel crush.
| Model | LBF-5025 | LBF-5050 | LBF-6080 |
| Power (KW) | 11~15 | 22 | 30~37 |
| Rotational Speed of Principal Axis(r/min) | 3000~3300 | 2800~3000 | 2000 |
| Chipping blade ( pcs ) | 2 | 2 | 2 |
| Hammer blade ( pcs ) | 16 | 32 | 72 |
| Capacity(kg/h) | 700~1000 | 1000~1500 | 1500~2000 |
| FeedingSize(Side) (mm) | 180 *180 | 180*180 | 230 *200 |
| Feeding (Above) Size(mm) | 250*220 | 500*220 | 800*300 |
| Sieve types for election(mm) | Ø 0.8~Ø20(the special can be customized,Ø3and lower need to with cyclone and dedusting bags.) | ||
| Packaging Dimension (mm) | 1600*800*1300 | 1600*1100*1300 | 2400*1600*1450 |
| Weight of machine body (kg) | 400 | 550 | 900 |
