Self Propelled Rotary Cultivation Multi Purposes Farm Crawler Tractor can be considered the most necessary piece of farm equipment a farmer should have. It performs a variety of farm tasks such as pl
Contact Us Product Center
Self Propelled Rotary Cultivation Multi Purposes Farm Crawler Tractor can be considered the most necessary piece of farm equipment a farmer should have. It performs a variety of farm tasks such as plowing, tilling, harrowing, shoveling, planting, hauling, transporting, lifting, and providing power supply.
1. With hydraulic turning and automatic transmission, it’s simple and comfortable for operating,travelling is easy to control, and turning is flexible. Right hand controls the turning, left hand controls the forward and backward travelling and the speeds as well as the up and down of the tools.
2. The machine is of compact structure and convenient for maintenance.
3. High adaptability, it can be operated on the water fields, dry fields and slope fields, suitable for plain areas and mountain areas.
4. Strong power, strong grade ability, it can pass the ridges conveniently and flexibly.
5. It’s of multi-purposes with optional tools, such as rotary cutters for dry fields, rotary cutters for water fields, tie ridgers, furrowers, ploughs etc.
6. The position of driving wheel is high, with high min. ground clearance, suitable for deep mud fields.
| 1. Matching power (kW) | 30-75kW |
| 2. Fuel consumption (kg / h㎡) | ≤ 17.6 |
| 3. Tillage (mm) | 1300-2300 |
| 4. Tillage depth (㎝) | dry farming ≥ 8 hydroponics ≥ 8 |
| 5. Rotary knife form IT245 and ridge dedicated blade | |
| 6. Percentage (%) | ≥50 |
| 7. Tillage surface roughness (㎝) | ≤ 5 |
| 8. Pure working hours productivity (h ㎡ / h) | ≥ 0.32 |
| 9. Knife shaft speed r / min 280-330 | |
