This Liquid Fertilizer Orchard Sprayer Machine is a liquid spread out farm machinery, is an agricultural spraying machinery, it mainly used for pest control, it can also be used for sanitation and disinfection of public spaces.
Liquid Fertilizer Orchard Sprayer Machine have those advantages: start convenient, compact, convenient transportation, long range, good atomization effect, large operating range, the unique back Stirrers, spraying good effect, easy maintenance and long service life.
Open the fuel tank cap, use a funnel with filter to join a clean 93 # gasoline, fuel filler amount up to two more drums highest scale line, finished filling cap tightened to prevent leaks, oil spills. Open the lid liquid medicine filling the funnel with a diluted liquid through strainer to join the drug barrel, does not exceed the maximum amount of liquid filling scale line, tighten the lid after completion, so as not to leak prevail.
|
Power |
7.5hp |
|
Speed |
Spray 800-1200rpm Flow 1400rpm |
|
Working pressure |
Spray 15-35kgf/cm2 Flow 10kgf/cm2 |
|
Horizontal range |
10-18m |
|
Tank capacity |
100L |
|
Water absorbing capacity |
Spray 14.5-22L/min Flow 25L/min |
|
Length of pipe |
According to your requirement |
